CoroMill® 178 – Cylindrical Tool For Power Skiving
The CoroMill® 178 power skiving concept now features a cylindrical tool, available in three different substrates for gear machining in three different application areas: steel, hardened steel and HRSA.
In multi-task machines, CoroMill® 178 cylindrical tool allows for one set-up machining, which will help saving time and reducing costs. At the same time, quality is never compromised thanks to the exceptional accuracy in run-out, pitch and output, with an outstanding finishing profile.
Features and benefits
CoroMill® 178 cylindrical tool for gear machining
- Three types of substrates for different material applications: steel, hardened steel and HRSA
- New machining scenarios, such as final machining after heat treatment and spline machining of titanium and HRSA items within the aerospace segment, are possible thanks to the new substrates
- Increased tool life, thanks to re-grinding treatment. The profile remains the same, without distortion
CoroMill® 178B shank
- Shank tool with centre coolant channel to prevent chip jamming
- De-brazing and re-brazing for increased sustainability
- The length of the shank is customizable—up to six times the diameter reach
Applications
- Internal and external gears and splines
- Cylindrical spur and helical gears
- Application range:
o DC range: 15.5–49.7 mm
o Shank diameter DCON: 8–25 mm
o Module range, spline: 0.8–5
o Module range, gear: 0.5–3
- Roughing to finishing
- Main industry segments: automotive, agriculture, aerospace, general machining
- Main components: automotive transmission components, gears, coupling components, splines, shafts, synchronization rings and CV joints.
